Retractable Tunnels

Price on Application

Our retractable tunnel concept is incredibly versatile and lends itself to a range of applications. Each order can be designed and manufactured according to clients needs. Large, small, fixed or retractable - whatever your situation, our Design & Installation team can find a solution to your search.

Folding garages, football tunnels, weatherproof walkways or temporary warehouses - no problem. Whichever industry, the right application is available: sports, retail or leisure

Designed and manufactured in Europe, our retractable tunnel solutions provide a perfect versatile solution

RETRACTABLE TUNNEL BROCHURE

Specifications

READY BOX 1 TUNNEL

READY BOX 1 EXTRA

READY BOX 2 TUNNEL

READY BOX 4 TUNNEL

READY BOX 6 TUNNEL

Technical Features

• Structural Engineering

  • Chassis: High-yield silver-anodized aluminum alloy (EN AW6060 T6).

  • Hardware: Stainless steel joints and specialized pantograph (scissor) systems for fluid mechanical retraction.

  • Compaction Ratio: 5m modules retract to approx. 35cm (varies by model); allows for 90%+ clear site recovery when closed.

  • Wind Loading: Certified for stability up to 100 km/h (with anti-lift tracks and lateral tensioning).

  • Snow Load: Rated at 0.10 $kN/m^{2}$ (EN13782 compliant); compatible with internal heating systems for snow mitigation.

  Membrane & Enclosure

  • Fabric: Ferrari Precontraint 502 PES-PVC; high-tenacity polyester with double-sided coating.

  • Compliance: M2/B1 Flame Retardant; UV-stabilized and anti-fungal treated.

  • Maintenance: Modular 1m roof panels with Keder strip inserts for rapid, localized replacement without full disassembly.

  • Visibility: Optional integrated high-transparency PVC windows and vision strips for natural internal lighting.

  Mobility & Site Adaptation

  • Foundation-Free: Engineered for installation on existing hardstands without traditional footings or permanent permits.

  • Wheel Systems: * Nylon/Pneumatic: For standard mobility.

    • Lift-Proof Tracks: Precision steel floor guides for high-wind safety.

    • Multi-Directional: 360° swivel wheels for lateral shifting and complex maneuvers.

  • Modular Linking: Standardized "Flashing" kits for hermetic sealing to buildings, containers, or secondary tunnels.

  Dimensional Matrix

  • Clear Span Widths: 1.0m up to 15.0m.

  • Eave Heights: 1.8m up to 5.0m.

  • Configurations: Curved Arch, Single-Pitch (Wall-mounted), or Double-Pitch Asymmetrical.

  Deployment & Operational Efficiency

  • Rapid Setup: Pre-assembled modular components; "Crate-to-Operational" in hours, not weeks.

  • Logistics: Designed for standard containerization (Model 1 Extra/XL) to minimize international freight costs.

  • Manual/Motorized: Options for ergonomic pull-handles or automated drive systems for high-frequency operation.


FAQ

Ordering & Customization

• Are "off-the-shelf" products available? No. To ensure structural integrity and a precise fit for your site, every tunnel is custom-engineered and manufactured to order.

• What are the frame specifications? The framework is constructed from high-grade silver-anodized aluminum. The integrated pantograph tensioning levers are finished in RAL 9006 (White Aluminum) for a professional, uniform appearance.

• What fabric options and colors are available? We utilize premium Poly RS ADR 650 GSM fabric.

  • Standard Palette: White, Grey, Champagne, Black, and Green.

  • Specialty Textiles: High-transparency "Clear Crystal" PVC, Blackout PVC (for light-sensitive operations), and integrated window or clear-roof sections for natural illumination.

Structural Capabilities & Dimensions

• What are the maximum available dimensions? * Span (Width): Up to 15m (50').

  • Clearance (Eave Height): Up to 5m (16'6").

  • Length: Scalable to your requirements; there is no maximum limit to the length of the run.

• What is the retraction ratio? Our systems are engineered for high-density storage. For example, a 10m (33') tunnel compacts to approximately 67cm (2'3") when fully retracted.

• Can the system accommodate uneven or curved sites? Yes. The modular design allows for vertical sloping to follow terrain gradients and can be engineered to navigate horizontal bends up to 90 degrees.

Safety, Engineering & Compliance

• Are the structures fire-rated? Yes. All membranes are certified to international fire safety standards, including:

  • Australia: AS 1530

  • USA: NFPA 701

  • Europe: UNI EN 13782:2015

• What is the wind-load rating? When deployed with a compliant anchoring system and the application of integrated tensioning straps, our tunnels are rated for wind resistance up to 100km/h (62 MPH).

• How is the structure secured or anchored? Standard configurations utilize heavy-duty wall-fix brackets. For freestanding models, we provide specialized anchoring kits tailored to your specific ground surface.

Mobility & Hardware

• What wheel and track options are available? We offer several hardware configurations based on the environment:

  • Nylon Wheels: 125mm (4.9") for standard hardstands.

  • Pneumatic / Rubber Wheels: 140mm–200mm (5.5"–8") for increased clearance and variable terrain.

  • Anti-Lift Tracks: Optional precision floor guides to ensure stability in high-wind regions.

Ground fix brackets

Concrete or water weights with tensioning straps

Is the tunnel difficult to deliver?

No. It's easily freighted in custom solid timber boxes

Safety Instructions

⚠️ SAFETY INSTRUCTIONS: Retractable Industrial Tunnels

1. Operational Safety

• Two-Person Rule: Manual opening and closing must be managed by two people, especially for larger structures, to ensure fluid and synchronized movement.

• Pinch Point Awareness: Keep hands and clothing clear of the scissor pantograph system (crossbars) during extension or retraction to avoid entrapment.

• Clearance: Ensure the path of the wheels is free from debris or obstacles before moving the tunnel to prevent sudden stops or tipping.

2. Environmental & Wind Safety

• Wind Resistance: The tunnel's safety is certified only when using appropriate anti-lift guides or lateral tie rods.

  • Standard Config: Maximum wind speed is significantly reduced without stability kits.

  • Reinforced Config: With lateral tie rods, stability is ensured up to 100 km/h for most models (e.g., Ready Box 1 Extra, XL, 2, 4, and 6).

• Snow Load: In the event of heavy snowfall, the structure must be monitored. If it is an unheated structure, snow accumulation should be cleared, or the PVC cover removed before storms to prevent structural failure.

3. Installation & Maintenance

• Anchoring: Always ensure the structure is securely anchored using the provided safety straps, steel cables, or ballasts (concrete or fillable plastic).

• Fire Safety: Only use original fireproof PVC sheets. Verify that the flame-retardant certification is valid and that no flammable materials are stored directly against the fabric.

• Regular Inspection: Periodically check the pantograph locking mechanisms and wheel integrity to maintain structural stability.

View full product details »

Negative Pressure Inflatable Medical or Industrial Tent

$16,300.00 AUD

Our easy to install inflatable Negative Pressure tent is designed to create a negative pressure environment inside the tent and reduce the risk of contamination.

What it is used for

- Triage medical tent for respiratory virus or contagious assessment

- Isolation or Intensive Care Unit (ICU)

- Medical tent

- Industrial safety tent

Features

Features of our Negative Pressure inflatable tent are

- Prevents the spread of contaminated air

- Provides more than 2.5 Pascal negative pressure when entry door is closed and sealed.

- 12 ACH (Air changes per hour) is possible with proper negative pressure unit.

- Rapid and easy deployment

- There are Pass boxes on the side of tent wall for access pipes or electrical ducting

Specifications

- Frame: Airtight inflatable fabric, 26 ~38 oz, 0.65mm ~ 0.9mm thick, Durable enough against

4.3 psi (Inside frame pressure)

- Cover: 600Deniar polyester coated by Polyurethane, Waterproof, Fire retardant and UV

treated. 0.4mm thick, 10oz

- Tent size: 13’ x 13’

- Tent height: 9’

- Weight: 150 lbs

- Time to inflate: About 5 minutes

- Custom sizes are available

View full product details »
